Network |
Network Storage |
NAS (NFS, SMB/ CIFS) |
Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets |
API |
ISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G,
Profile T), ISUP |
Simultaneous Live View |
Up to 20 channels |
User/Host |
Up to 32 users. 3 levels: Administrator, Operator and User |
Security |
Authenticated username and password, MAC address binding, HTTPS encryption,
802.1X authenticated access, IP address filter |
Web Browser |
IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
Image |
Day/Night Switch |
Day, night, auto, scheduled-switch |
Image Enhancement |
BLC, HLC, 3D DNR |
Wide Dynamic Range (WDR) |
120 dB WDR |
Defog |
Digital defog |
Regional Exposure |
Yes |
Image Settings |
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by
client software or web browser |
Image Parameters Switch |
Yes |
Privacy Mask |
Up to 24 masks (8 masks for each scene) |
SNR |
>52 dB |
Interface |
Built-in Speaker |
1 built-in speaker |
Power Output |
12 VDC; < 60 mA |
Ethernet Interface |
1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at) |
On-board Storage |
Built-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB |
Alarm |
1 input, 1 output |
Audio |
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω |
RS-485 |
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
Reset |
Yes |
Event |
Basic Event |
Video tampering alarm, motion detection, alarm input, alarm output, exception |
Smart Event |
Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio
exception detection |
Alarm Linkage |
Preset, memory card video recording, alarm output, sending email, notify surveillance
center, upload to FTP, audible warning, white light flashing |
Deep Learning Function |
Face Capture |
Detects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting
of face in motion, and outputs the best face picture |
Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle) |
