Web Browser |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
Image |
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software
or web browser |
Day/Night Switch |
Auto, Schedule, Day, Night |
Image Enhancement |
BLC, 3D DNR |
Interface |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage |
Built-in memory card slot, support microSD card, up to 256 GB |
Audio |
-S:
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output
impedance: 100 Ω, interface type: non-equilibrium |
Alarm |
-S: 1 input,1 output, (max. 12 VDC, 30 mA) |
Event |
Basic Event |
Motion detection, video tampering alarm, exception |
Smart Event |
Line crossing detection, intrusion detection |
Linkage |
-S: Upload to FTP, notify surveillance center, send email, upload to memory card,
trigger recording, trigger capture, audible warning, trigger alarm output |
Interface |
Reset |
Yes |
General |
Power |
12 VDC ± 25%, 0.8 A, max. 10 W, Ø5.5 mm coaxial power plug
PoE: (802.3af, Class 3, 36 V to 57 V), 0.21 A to 0.33 A, max. 12 W |
Camera Dimension |
Ø153 .3 mm × 111.6 mm (6" × 4.4 ") |
Package Dimension |
239 mm × 169 mm × 160 mm (9.4" × 6.7" × 6.3") |
Camera Weight |
Approx. 880 g (1.9 lb.) |
With Package Weight |
Approx. 1300 g (2.9 lb.) |
Storage Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) |
Startup and Operating
Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) |
Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese,
Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP
address filter |
