| Camera |
| Max. Resolution |
2560 × 1440 |
| Image Sensor |
1/2.8 inch progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux@(F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/1 s to 1/30000 s |
| Slow Shutter |
Yes |
| Day & Night |
IR cut filter |
| Zoom |
25x optical, 16x digital |
| Lens |
| Focal Length |
4.8 mm to 120 mm |
| Zoom Speed |
Approx. 4.8 s |
| FOV |
Horizontal field of view: 50.8° to 2.6° (wide-tele), |
| Vertical field of view: 29.4° to 1.5° (wide-tele), |
| Diagonal field of view:57.4° to 3° (wide-tele) |
| Aperture |
Max. F1.6 |
| Focus |
Auto, semi-auto, manual |
| Illuminator |
| Supplement Light Type |
IR |
| Supplement Light Range |
IR Distance: up to 200 m |
| PTZ |
| Movement Range (Pan) |
360° |
| Movement Range (Tilt) |
-15° to 90° (auto flip) |
| Pan Speed |
Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s |
| Tilt Speed |
Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s |
| Proportional Pan |
Yes |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 32 presets for each patrol |
| Pattern Scan |
4 pattern scans |
| Power-off Memory |
Yes |
| Park Action |
Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning |
Yes |
| PTZ Status Display |
Yes |
| Preset Freezing |
Yes |
| Scheduled Task |
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Video |
| Main Stream |
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); |
| 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); |
| 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); |
| 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 |
| Sub-stream: H.265/H.264/MJPEG |
| Third stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 kbps to 16384 kbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region of Interest (ROI) |
8 fixed regions for each stream |
| Audio |
| Audio Compression |
G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16-64 Kbps (AAC) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Network |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API |
Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users, 3 user levels: administrator, operator, and user |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Client |
iVMS-4200, HikCentral Pro, Hik-Connect |
| Web Browser |
IE11, Chrome 57+, Firefox 52+, Safari 11+ |
| Image |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Wide Dynamic Range (WDR) |
120 dB |
| Defog |
Digital defog |
| Image Stabilization |
EIS |
| Regional Exposure |
Yes |
| Regional Focus |
Yes |
| Image Settings |
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| Privacy Mask |
24 programmable polygon privacy masks, mask color or mosaic configurable |
| SNR |
> 52 dB |
| Interface |
| Ethernet Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board Storage |
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256GB |
| Alarm |
2 inputs, 1 output |
| Reset |
Yes |
| Audio |
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω |
| Built-in Speaker |
1 built-in speaker with effective distance reaching max. 30 meters |
| Event |
| Basic Event |
Motion detection, video tampering alarm, exception, alarm input and output |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection |
| Smart Tracking |
Manual tracking, auto-tracking |
| Alarm Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Deep Learning Function |
| Face Capture |
Detects up to 5 faces simultaneously. |
| Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting |
| Support alarm triggering by specified target types (human and vehicle) |
| General |
| Power |
24 VAC, max. 42 W (including max. 18 W for IR and max. 10 W for heater); Hi-PoE |
| Operating Condition |
-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) |
| Demist |
Yes |
| Material |
ADC12 |
| Dimension |
Ø 220 mm × 363.3 mm |
| Weight |
Approx. 5 kg |
| Approval |
| Protection |
IP66 (IEC 60529-2013), IK10 (excluding glass window), TVS 6000V lightning protection, surge protection and voltage transient protection |
| EMC |
FCC SDoC (47 CFR Part 15, Subpart B); |
| CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2019); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (SANS IEC60950-1) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
