Camera |
Image Sensor: | 1/2.8″ HD progressive scan CMOS |
Effective Pixels: | 1920(H)x1080(V) |
Signal System: | PAL/NTSC |
Minimum Illumination: | Color: 0.005 Lux @(F1.6, AGC ON) |
B/W: 0.001Lux @(F1.6, AGC ON) |
0 Lux with IR |
White Balance: | Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
AGC: | Auto/Manual |
BLC: | ON/OFF |
HLC: | Support |
Smart defog: | Support |
WDR: | 120dB |
Shutter Time: | 1-1/10,000s |
Day& Night: | ICR |
Digital Zoom: | 16X |
Privacy Mask: | 24 programmable privacy masks; optional multiple colors and mosaics |
Auto Focus: | Auto / Semi-automatic / Manual |
Lens |
Focal Length: | 4.8 mm to 120 mm, 25× optical zoom |
Zoom Speed: | Approx. 3.6 s (optical lens, wide-tele) |
Field of View: | Horizontal field of view: 57.6° to 2.5° (Wide-Tele) |
Vertical field of view: 34.4° to 1.4° (Wide-Tele) |
Diagonal field of view: 64.5° to 2.9° (Wide-Tele) |
Minimum Working Distance: | 10-1,500mm(Wide-Tele) |
Aperture Range: | F1.6 to F3.5 |
Pan & Tilt |
Pan Range: | 360°endless |
Pan Speed: | Configurable, from 0.1°/s to 120°/s |
Preset speed: 120°/s |
Tilt Range: | -15°-90° (Auto Flip ) |
Tilt Speed: | Configurable, from 0.1°/s to 80°/s |
Preset Speed: 80°/s |
Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples |
Number of Preset: | 300 |
Patrol: | 8 patrols, up to 32 presets per patrol |
Pattern: | 4 pattern scans, record time over 10 minutes for each scan |
Power-off Memory: | Support |
Park Action: | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
PTZ Position Display: | ON/OFF |
Infrared |
IR Distance: | 150m |
IR irradiation angle: | Adjustable by zoom |
Network |
Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector |
Max.Image Resolution: | 1920×1080 |
Main Stream: | 50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ; |
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720) |
Sub Stream: | 50Hz: 25fps(704×576, 640×480,352×288); 60Hz: 30fps(704×480, 640×480,352×240) |
Third Stream: | 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288) |
60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288) |
Video Compression: | Main Stream: H.265+/H.265/H.264+/H.264 |
Sub-Stream: H.265/H.264/MJPEG |
Third Stream: H.265/H.264/MJPEG |
ROI encoding: | Support 4 areas with adjustable levels |
Audio Compression: | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
Audio Mode: | OFF/Audio input/Audio output |
Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
Simultaneous Live View: | Up to 20 channels |
Three-Stream: | Support |
Storage: | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
User/Host: | Up to 32 users, 3 levels: Administrator, Operator and User |
Security Measures: | User authentication (ID and PW), host authentication (MAC address) |
Hik-Connect: | Support |
Client GUI |
Client: | iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
Web Browser: | IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
General |
Language: | English |
Power Supply: | 24 VAC and PoE+ |
Power Consumption: | Max.: 30 W (Max. 10 W for IR) |
Working Temperature/Humidity: | -30 ℃-65℃(-22℉-149℉)(outdoor) |
90% or less |
Protection Level: | IP66 standard (outdoor dome) |
TVS 4,000V lightning protection, surge protection and voltage transient protection |
Mounting: | Various mounting modes optional |
Material: | ADC 12, PC, PC+10%GF |
Dimensions: | Φ 208 mm × 345 mm (Φ 8.19″ × 13.58″) |
Weight (approx.): | Approx. 3.3 kg (7.28 lb) |
