| System |
| Main Processor |
Industrial-grade processor |
| Operating System |
Embedded Linux |
| Operating Interface |
Web; Local GUI |
| Perimeter Protection |
| Perimeter Performance AI by Recorder (Number of Channels) |
2 channel, 10 IVS rules for each channel |
| Face Detection |
| Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) |
2 channels (up to 12 face images/s) |
| Face Recognition |
| Face Database Capacity |
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture |
| Face Recognition Performance of AI by Recorder (Number of Channels) |
2 channels |
| SMD Plus |
| SMD Plus by Recorder |
16 channels: Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change, secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change |
| Audio and Video |
| Analog Camera Input |
16 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto-detect |
| Camera Input |
1. CVI: 4K, 6 MP, 5 MP, 4 MP, 1080P@25/30 fps, 720P@50/60 fps, 720P@25/30 fps. |
| 2. TVI: 4K, 5 MP, 4 MP, 3 MP, 1080P@25/30 fps, 720P@25/30 fps. |
| 3. AHD: 4K, 5 MP, 4 MP, 3 MP, 1080P@25/30 fps, 720P@25/30 fps. |
| IP Camera Input |
Up to 32 channels of IPC access |
| 16 IP channels by default + 16 channels (analog channels are converted to IP channels) |
| incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps |
| Encoding Capacity |
Main stream: All channel 4K@(1-7 fps); 6MP@ (1-10 fps); 5MP@ (1-12 fps); 4K-N/4 MP/3 MP@ (1-15 fps); 4M-N/1080P/720P/960H/D1/CIF (1fps–25/30fps); |
| Sub stream: 960H@ (1 fps–15 fps); D1/CIF@ (1 fps–25/30 fps) |
| Dual-stream |
Yes |
| Video Frame Rate |
PAL: 1 fps–25 fps. |
| NTSC: 1 fps–30 fps |
| Video Bit Rate |
32 kbps–6144 kbps per channel |
| Audio Sampling |
8 kHz, 16 bit |
| Audio Bit Rate |
64 kbps |
| Video Output |
1 HDMI ,1 VGA |
| HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-screen Display |
When IP extension mode not enabled: 1/4/8/9/16 |
| When IP extension mode enabled: 1/4/8/9/16/25/36 |
| Third-party Camera Access |
Onvif, RTSP, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung |
| Compression Standard |
| Video Compression |
AI Coding; H.265+; H.265; H.264+;H.264 |
| Audio Compression |
G.711a; G.711u; PCM |
| Network |
| Network Protocol |
HTTP; HTTPS; TCP / IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P |
| Mobile Phone Access |
iOS, Android |
| Interoperability |
ONVIF 21.06, CGI |
| Browser |
Chrome, IE9 or later, Firefox |
| Network Mode |
Single-address mode |
| Recording Playback |
| Record Mode |
General, motion detection; intelligent; alarm; POS |
| Recording Playback |
When the AI Function (IVS, FACE) is not enabled: 1/4/9/16 |
| When the AI Function (IVS, FACE) is enabled: 1/4/9 |
| Backup Method |
USB device and network |
| Playback Mode |
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Alarm |
| General Alarm |
Motion detection, video loss, tampering, and local alarm |
| Anomaly Alarm |
No disk, storage error, low space, offline, IP conflict, MAC conflict |
| Intelligent Alarm |
Face detection, face recognition, perimeter protection |
| Alarm Linkage |
Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| Ports |
| Audio Input |
1-channel RCA (external) |
| 16-channel BNC (coaxial audio) |
| Audio Output |
1-channel RCA |
| Two-way Talk |
Yes (share the same audio input with the first channel) |
| HDD Interface |
1 SATA port,up to 16 TB, the maximum HDD capacity varies with environment temperature |
| RS-485 |
1 |
| USB |
2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI |
1 |
| VGA |
1 |
| Network Port |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply |
12 VDC, 3A |
| Power Consumption |
Lower than 15W |
| Net Weight |
1.23 kg (2.71 lb) |
| Gross Weight |
2.11 kg (4.65 lb) |
| Product Dimensions |
Mini 1U, 325× 256.6× 55 mm (W × D × H) |
| Packaging Dimensions |
372 × 117 × 308 mm (W × D × H) |
| Operating Temperature |
–10 °C to +55 °C (14 °F to +131 °F) |
| Operating Humidity |
10%–90% (RH) |
| Installation |
Desktop |
