| System |
| Main Processor |
Embedded processor |
| Operating System |
Embedded linux |
| Perimeter Protection |
| Performance |
1 channel, 10 IVS for each channel |
| Object classification |
Human/Vehicle secondary recognition for tripwire and intrusion |
| AI Search |
Search by target classification (Human, Vehicle) |
| Face Recognition |
| Performance |
Max 8 face pictures/sec processing |
| 1 channel video stream face recognition, only support analog camera |
| Stranger Mode |
Detect strangers' faces (not in device's face database). Similarity threshold can be set manually |
| AI Search |
Up to 8 target face images search at same time, similarity threshold can be set for each target face image |
| Database Management |
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture |
| Database Application |
Each database can be applied to video channels independently |
| Trigger Events |
Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc. |
| SMD Plus |
| Performance |
4 channels |
| AI Search |
Search by target classification (Human, Vehicle) |
| Video and Audio |
| Analog Camera Input |
4 channels, BNC |
| HDCVI Camera Input |
4K, 6MP, 5MP, 4MP, 1080p@ 25/30 fps, 720p@ 50/60 fps,720p@ 25/30 fps |
| AHD Camera Input |
4K, 5MP, 4MP, 3MP, 1080p@ 25/30 fps, 720p@ 25/30 fps |
| TVI Camera Input |
4K, 5MP, 4MP, 3MP, 1080p@ 25/30 fps, 720p@ 25/30 fps |
| CVBS Camera Input |
PAL/NTSC |
| IP Camera Input |
4+4 channels, each channel up to 8MP |
| Audio In/Out |
1/1, RCA |
| Two-way Talk |
Reuse audio in/out, RCA |
| Recording |
| Compression |
AI Coding/H.265+/H.265/H.264+/H.264 |
| Resolution |
4K; 6MP; 5MP; 4MP; 3MP; 4M-N; 1080P; 720P; 960H; D1; CIF |
| Record Rate |
Main stream: All channel 4K (1 fps–7 fps); 6MP (1 fps–10 fps); 5MP (1 fps–12 fps); 4MP/3MP (1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF (1 fps–25/30 fps); |
| Sub steram:960H (1 fps–15 fps); D1/CIF(1 fps–25/30 fps) |
| Bit Rate |
32 kbps–6144 kbps per channel |
| Record Mode |
Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop |
| Record Interval |
1 min– 60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s |
| Audio Compression |
G.711A; G.711U; PCM |
| Audio Sample Rate |
8 KHz, 16 bit per channel |
| Audio Bit Rate |
64 kbps per channel |
| Display |
| Interface |
1 HDMI; 1 VGA |
| Resolution |
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-screen Display |
When IP extension mode not enabled: 1/4 |
| When IP extension mode enabled: 1/4/8/9 |
| OSD |
Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
| Network |
| Interface |
1 RJ-45 Port (100 MB) |
| Network Function |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wi-Fi; 3G/4G; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access |
128 users |
| Smart Phone |
iPhone; iPad; Android |
| Interoperability |
ONVIF 16.12, CGI Conformant |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Playback and Backup |
| Playback |
4-Jan |
| Search Mode |
Time/Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
| Backup Mode |
USB Device/Network |
| Storage |
| Internal HDD |
1 SATA port, up to 10 TB capacity |
| Auxiliary Interface |
| USB |
2 USB ports (USB 2.0) |
| RS485 |
1 port, for PTZ control |
| Electrical |
| Power Supply |
DC 12V/2A |
| Power Consumption (Without HDD) |
< 7W |
| Construction |
| Dimensions |
Compact 1U, 260.0 mm × 237.9 mm × 47.6 mm |
| Net Weight |
0.53 kg (1.17 lb) |
| Gross Weight |
1.07 kg (2.36 lb) |
| Installation |
Desktop installation |
| Environmental |
| Operating Conditions |
-10°C to +55°C (+14°F to +131°F), 0%–90% (RH) |
| Storage Conditions |
-20°C to +70°C (-4°F to +158°F) , 0%–90% (RH) |
| Third-party Support |
| Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
