- Cam kết giá Đầu ghi hình 16 kênh Turbo ACUSENSE iDS-7216HQHI-M2/S tốt nhất thị trường
- Hỗ trợ hướng dẫn sử dụng, cách lắp đặt 24/7
- Sản phẩm Đầu ghi hình 16 kênh Turbo ACUSENSE iDS-7216HQHI-M2/S mới 100%
- Bảo hành sản phẩm 24 tháng nếu lỗi đến từ nhà sản xuất
| Model | iDS-7216HQHI-M2/S |
| Motion Detection 2.0 | |
| Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; |
| Perimeter Protection | |
| Human/Vehicle Analysis | Up to 4-ch |
| Recording | |
| Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding resolution | Main stream: |
| When 1080p Lite mode not enabled: | |
| For 4 MP stream access: | |
| 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) | |
| For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps | |
| For 1080p stream access: | |
| 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) | |
| For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) | |
| When 1080p Lite mode enabled: | |
| 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps(N) | |
| Sub-stream: | |
| WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N) | |
| Video bitrate | 32 Kbps to 6 Mbps |
| Dual stream | Support |
| Stream type | Video, Video & Audio |
| Audio compression | G.711u |
| Audio bitrate | 64 Kbps |
| Video and Audio | |
| IP video input | 2-ch (up to 18-ch) |
| Enhanced IP mode on: 8-ch (up to 24-ch), each up to 4 Mbps | |
| Up to 6 MP resolution | |
| Support H.265+/H.265/H.264+/H.264 IP cameras | |
| Analog video input | 16-ch |
| BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection | |
| HDTVI input | 4 MP, 3 MP, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps |
| *: The 3 MP signal input is only available for channel 1/2 of iDS-7208HQHI-M2/S, and for channel 1/2/3/4 of iDS-7216HQHI-M2/S. | |
| AHD input | 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| HDCVI input | 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| CVBS input | PAL/NTSC |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI/VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI/VGA simultaneous output |
| Audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| 16-ch via coaxial cable | |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Synchronous playback | 16-ch |
| Network | |
| Remote connection | 128 |
| Network protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network interface | 1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Wi-Fi | Connectable to Wi-Fi network by Wi-Fi dongle through USB interface |
| Auxiliary interface | |
| SATA | 2 SATA interfaces, up to 10 TB capacity for each disk |
| Serial interface | RS-485 (half-duplex) |
| USB interface | Front panel: 1 × USB 2.0; |
| Rear panel: 1 × USB 3.0 | |
| General | |
| Power supply | 12 VDC, 3.3 A |
| Consumption (without HDD) | ≤ 40 W |
| Working temperature | -10°C to 55 °C (14 °F to 131 °F |
| Working humidity | 10% to 90% |
| Dimension (W × D × H) | 380 × 320 × 48 mm |
| Weight (without HDD) | ≤ 2 kg |
• 16 ngõ vào video,chuẩn nén H.265 Pro+/H.265 Pro/H.265/ H.264+, H.264
• Hỗ trợ camera HD TVI , HD CVI , AHD , Analog.
• Hỗ trợ truyền âm thanh qua cáp đồng trục
• Gán thêm 08 camera IP 4MP ( khi chưa tắt các kênh analog. Gán tối đa 24 camera IP 4MP khi tắt tất cả các kênh analog
• iDS-7216HQHI-M2/S Hỗ trợ truyền âm thanh qua cáp đồng trục
• 02 cổng SATA hỗ trợ ổ cứng tối đa 10TB
• Cổng HDMI @1920×1080 ; VGA @1920×1080; 01 ngõ ra CVBS
• 01 x RJ45 10/100M;02 x USB 2.0; 01 x RS485
• Có thể kết nối wifi nếu có usb thu wifi
• Tính năng thông minh VCA
• Tính năng phát hiện khuôn mặt ở trên 1 kênh analog
• Lọc báo động người/ phương tiện 4 kênh
• Nguồn 12VDC, 2.5A/3.3A
Chưa có hỏi đáp nào.
